Hunter PGP Ultra Rotary Sprinklers | 20 PACK

Click image to enlarge

PGP Model with 12 nozzles - 4" Pop-up (10 cm) - 20-PACK
HR-PGP-ULTRA-20PACK
Quantity x

The PGP Ultra takes the foundation of the best-selling PGP Rotor and raises the bar with a variety of new features developed over three decades of research, customer feedback, and lab testing. Among the most notable improvements of the PGP Ultra is its non-strippable drive and automatic arc return. These two features work to allow the turret to be turned without causing damage, and return the turret to its original arc regardless of where it is turned. Other advanced features include 22 nozzle options with several radius choices, and a headed slot and set screw. The diversity of the PGP Ultra offers system installers an array of efficient options on any site.

Each PGP Ultra comes with an easy-to-install, square top rack of 8 standard nozzles and 4 low angle nozzles.

It is compatible with all major brands of gear drive rotors including Orbit, Rain Bird and Toro.

FEATURES & BENEFITS

  • Adjustable— Key adjusts arc from 50 to 360 degrees, and radius can be reduced up to 25 percent.
  • Precision Reversing Mechanism— Provides years of smooth non-delayed forward and reverse rotation.
  • Rubber Cover—Keeps the dirt out of adjustment components.
  • Lubricated Gear Assembly— For years of reliable use.
  • Pop-up sprinklers rotate silently then dissappear when the job is done.
  • Waters evenly and efficiently.
  • Has precise pattern control with no bothersome backsplash onto walkways or buildings.
  • Whisper quiet rotation, without impact or clatter.
  • Through-the-top adjustment with helpful symbol makes it easy to adjust, wet or dry.
  • Easy fine-tuning without changing nozzles.
  • Large dirty water screen puts an end to nozzle clogging.

OPERATION RANGE

  • Radius: 16' to 42’ (4.9 to 14.0 m)
  • Radius may be reduced up to 25% with radius reduction screw
  • Pressure 30-70 psi (1.7 to 4.5 Bars: 170 to 450 kPa)
  • Flow rate: 0.5 to 14.4 GPM (1,2 à 53,8 l/min)

SPECIFICATIONS

  • 3/4" FNPT bottom inlet
  • Nozzle outlet trajectory is 25 degree standard

DIMENSIONS

  • Overall Height: 7-3/8" (19 cm)
  • Exposed surface diameter: 1-3/4" (4 cm)
  • Popup Height: 4" (10 cm)

Made in U.S.A. 3 years warranty.
